NTMD4884NF
Power MOSFET and
Schottky Diode
30 V, 5.7 A, Single N-Channel with 30 V,
2.8 A, Schottky Barrier Diode
Features
? FETKY t Surface Mount Package Saves Board Space
? Independent Pin-Out for MOSFET and Schottky Allowing for
http://onsemi.com
?
?
?
Design Flexibility
Low R DS(on) MOSFET and Low V F Schottky to Minimize
Conduction Losses
Optimized Gate Charge to Minimize Switching Losses
This is a Pb-Free Device
V (BR)DSS
30 V
N-CHANNEL MOSFET
R DS(on) Max
48 m W @ 10 V
70 m W @ 4.5 V
I D Max
5.7 A
Applications
? Disk Drives
? DC-DC Converters
? Printers
MOSFET MAXIMUM RATINGS (T J = 25 ° C unless otherwise stated)
V R Max
30 V
SCHOTTKY DIODE
V F Max
0.5 V
S
A
I F Max
2.8 A
Rating
Drain-to-Source Voltage
Gate-to-Source Voltage
Symbol
V DSS
V GS
Value
30
± 20
Unit
V
V
Continuous Drain
T A = 25 ° C
I D
4.7
A
G
Current R q JA (Note 1)
T A = 70 ° C
3.8
Power Dissipation
R q JA (Note 1)
Continuous Drain
T A = 25 ° C
T A = 25 ° C
P D
I D
1.6
3.3
W
A
D
N-Channel MOSFET
C
Schottky Diode
Current R q JA (Note 2)
Steady
T A = 70 ° C
2.6
Power Dissipation
State
T A = 25 ° C
P D
0.77
W
MARKING DIAGRAM
R q JA (Note 2)
& PIN ASSIGNMENT
Continuous Drain
Current R q JA t < 10 s
(Note 1)
T A = 25 ° C
T A = 70 ° C
I D
5.7
4.5
A
8
C C D D
Power Dissipation
R q JA t < 10 s (Note 1)
Pulsed Drain Current
T A = 25 ° C
T A = 25 ° C,
t p = 10 m s
P D
I DM
2.3
19
W
A
8
1
SOIC-8
CASE 751
STYLE 18
1
4884NF
AYWW
G
A A S G
Operating Junction and Storage Temperature
Source Current (Body Diode)
Lead Temperature for Soldering Purposes
(1/8 ″ from case for 10 s)
T J , T STG
I S
T L
-55 to
+150
1.3
260
° C
A
° C
4884NF = Device Code
A = Assembly Location
Y = Year
WW = Work Week
G = Pb-Free Package
SCHOTTKY MAXIMUM RATINGS (T J = 25 ° C unless otherwise stated)
Peak Repetitive Reverse Voltage
V RRM
30
V
ORDERING INFORMATION
DC Blocking Voltage
V R
30
V
Device
Package
Shipping ?
Average Rectified Forward
Current, (Note 1)
Steady
State
I F
2.8
A
NTMD4884NFR2G
SOIC-8
2500/Tape & Reel
t < 10 s
? Semiconductor Components Industries, LLC, 2008
March, 2008 - Rev. 0
4.1
1
(Pb-Free)
?For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specification
Brochure, BRD8011/D.
Publication Order Number:
NTMD4884NF/D
